Home > PRODUCTS > Swing Gate Opener > 400KGS Dual Arms
450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates 450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates 450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates 450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates 450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates 450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates

450KGS 24V DC 500mm Heavy-Duty Gate Opener for Large Swing Gates

  • Protection class:

    IP55

  • Max. actuator travel:

    500mm

  • Max. weight:

    450KG per leaf

  • Motor voltage:

    DC 24V

  • Input power:

    AC 110V/220V ± 10%
Contact us
  • Overview
  • Features
  • Specs
  • One Set

Overview





Features




Specs


PKM-C035
Power supply
220V/110V ±10％
Motor
DC 24V
Motor power
80W x 2
Rated speed
77RPM
Actuator running speed
2.5cm/s
Actuator stroke
500mm
Max single leaf widt
3.5M
Max single leaf weight
4500KGS
Housing material
Aluminum, Stainless steel
Work temperatur
-20℃ ~ +55℃
Protection clas
IP55
WiFi & Bluetooth Control
Need to adopt smart control board
