800KG Gear System Residential Electric Gate Motor Sliding Gate Opener

800KG Gear System Residential Electric Gate Motor Sliding Gate Opener

Overview
Features
Specs
One Set

Overview

PYM-N2208

The AC powered sliding gate opener is designed to operate sliding gates up to 800kg in weight. It is an all in one motor and control panel, making it simple to install and extremely compact and neat.



* Weatherproof

* Manual Release

* All Metal Gears

* Metal Gear Drive

* All in one internal Motor and Weather Proof control panel

1-PYM-N 磁限位4.jpg

1-PYM-N 弹簧限位4.jpg

Features

Built in control panel making installation compact, neat simple

Limit switch allowing the motor to switch off once the cycle is finished

Built in manual release in case of emergency or power off

The motor is contructed of all metal gears making it durable and long lasting

Specs

Model No	PYM -N2208
Rated Voltage	220V±10%/110V±10%
Rated Motor Power	130W
Electric Motor	220VAC/110VAC 130W
Max Loading Weight	800KG
Output Torque	21N.m
Output Speed	50r/min±10%
Max. Pull Force	950N
Gear Modulus	M=4
Open/Close Speed	26cm/s
Limit Switch Type	Magnetic/Spring
Noise	≤55dB
Working Temperature	-20°C ~ +55°C
Duty Cycle	80%
WiFi & Bluetooth Control	Need to adopt smart control board
